TCEP

TCEP is a research project that provides a programming model for development of operator placement algorithms for streaming applications and a means to adapt operator placement by supporting transitions.

TCEP contributes the following:

Programming model to implement operator placement algorithms including algorithms from the state-of-the-art (see list below)
Transition execution strategies for a cost-efficient and seamless operator placement transition
Lightweight learning strategy for selection of operator placement for the given QoS demands
Heterogeneous infrastructure support for execution of operator graphs

To run TCEP simply do ./scripts/build.sh && docker-compose up. Check out our live demo at GENI!

List of Operator Placement Algorithms

Our version of Relaxation algorithm (from Pietzuch et al.)
Our version of MDCEP algorithm (from Starks et. al.)
Our version of MOPA algorithm (from Rizou et al.)
Our version of Global Optimal algorithm
Producer Consumer operator placement
Random operator placement

Video of the demo

Getting Started

Prerequisites

Docker v19.03 or later and a registry account
JDK8
sbt

Running on a central server (centralized execution)

Simply build TCEP and run using docker-compose ./scripts/build.sh && docker-compose up

Running cluster simulation (distributed execution)

Adjust $PROJECT_HOME/scripts/templates/docker-swarm.cfg as indicated in the file

Simulation can be executed using a GUI (mode 7) or without a GUI. The mode can be set in $PROJECT_HOME/docker-stack.yml file as an environment variable in simulator service.

A full list of simulations can be found below:

Mode	Description
1	Test Relaxation algorithm
2	Test MDCEP algorithm
3	Test SMS transition
4	Test MFGS transition
5	unavailable
6	Do nothing
7	Test with GUI
8	Test Rizou
9	Test Producer Consumer
10	Test Optimal
11	Test Random
12	Test Lightweight

./scripts/publish-tcep.sh all $user@$IP

the script will deploy the docker stack defined by docker-stack.yml to the cluster formed by the VMs

Running using GENI/ CloudLab VMs

GENI and CloudLab provides a large-scale experiment infrastructures where users can obtain computing instances throughout the world to perform network experiments. TCEP includes useful scripts to enable easier simulations on GENI which are described below.

cd scripts/

First, a so called RSpec XML file is needed in order to get a GENI/CloudLab cluster up and running. To automatically generate a cluster with a specified number of nodes you can execute the following command:

python generate_geni_rspec.py {number-of-nodes} {out-directory}

This will generate the rspec.xml file with the at “out-directory” with the specified number of nodes. Furthermore, this also generate the Docker swarm file (docker-swarm.cfg) with the correct amount of empty apps running on the GENI hosts.

After you deployed the RSpec on GENI, you can download a Manifest XML file which contains information of the hosts that GENI deployed. This is useful because GENI automatically generates IP addresses for the hosts and if you created a cluster with a high amount of nodes the search for this IP addresses can be a heavy overhead. After downloading the manifest file you can run the following command to extract the IP addresses out of it and print out the config that can be put into the “docker-swarm.cfg” file:

python manifest_to_config.py {manifest-path}

This will convert the manifest and will print out the IP addresses of the started hosts in the config format for the docker deploy script. You should see an output like this

manager=72.36.65.68
workers=("72.36.65.69" "72.36.65.70")

Now the hosts are successfully deployed on GENI and the project is ready to be setup on the hosts. To setup the GENI instances to be able to run docker, run the following command

./publish_tcep.sh setup

Note that you maybe have to enter yes in the console multiple times to allow SSH connections to the hosts

If you are running on a new cluster you never worked on before, you will maybe need to authorize docker on the master node to be authorized to access a private docker registry. You can do this by executing the following on the master node

docker login

After the instances are all setup, you can go forward and finally run the cluster on the hosts by executing the following command

./publish_tcep.sh all

Differences to CloudLab

The steps from above are the same, except that you have to replace the name of the RSpec image to be used before calling the generate script.

Specifically, you have to replace this line in scripts/templates/rspec_node.xml

<disk_image xmlns="http://www.geni.net/resources/rspec/3" name="urn:publicid:IDN+emulab.net+image+emulab-ops:UBUNTU16-64-STD"/>

with this line

<disk_image xmlns="http://www.geni.net/resources/rspec/3" name="urn:publicid:IDN+utah.cloudlab.us+image+schedock-PG0:docker-ubuntu16:0"/>

This project is based on AdaptiveCEP for specifying complex events and QoS demands.

Publications

M. Luthra, B. Koldehofe, N. Danger, P. Weisenbergera, G. Salvaneschi, I. Stavrakakis, TCEP: Transitions in operator placement to adapt to dynamic network environments. In Journal of Computer and Systems Sciences (JCSS), Special Issue on Algorithmic Theory of Dynamic Networks and its Applications, pp. 94-125, 2021. 10.1016/j.jcss.2021.05.003
M. Luthra, S. Hennig, K. Razavi, L. Wang, and B. Koldehofe, Operator as a Service: Stateful Serverless Complex Event Processing. In: Proceedings of the IEEE International Conference on Big Data Workshop, pp. 1964-1973, IEEE, December 2020. 10.1109/BigData50022.2020.9378142
M. Luthra, B. Koldehofe, R. Arif, P. Weisenburger, G. Salvaneschi, TCEP: Adapting to Dynamic User Environments by Enabling Transitions between Operator Placement Mechanisms. In Proceedings of the 12th ACM International Conference on Distributed and Event-based Systems (DEBS ’18), pp. 136–147. 10.1145/3210284.3210292
P. Weisenburger, M. Luthra, B. Koldehofe and G. Salvaneschi, Quality-Aware Runtime Adaptation in Complex Event Processing. In IEEE/ACM 12th International Symposium on Software Engineering for Adaptive and Self-Managing Systems (SEAMS ‘17), pp. 140-151. 10.1109/SEAMS.2017.10
M. Luthra, S. Hennig, B. Koldehofe, Understanding the Behavior of Operator Placement Mechanisms on Large Scale Networks. In the Proceedings of 19th ACM/IFIP/USENIX International Middleware Conference 2018: Posters and Demos (Middleware 2018), pp. 19-20. 10.1145/3284014.3284024
M. Luthra, B. Koldehofe, R. Steinmetz, Transitions for Increased Flexibility in Fog Computing: A Case Study on Complex Event Processing. Informatik Spektrum 42, pp. 244–255 (2019). 10.1007/s00287-019-01191-0
M. Luthra and B. Koldehofe, ProgCEP: A Programming Model for Complex Event Processing over Fog Infrastructure. In Proceedings of the 2nd International Workshop on Distributed Fog Services Design @ Middleware Conference (DFSD ’19@Middleware), pp. 7-11. 10.1145/3366613.3368121

Acknowledgement

This work has been co-funded by the German Research Foundation (DFG) within the Collaborative Research Center (CRC) 1053 – MAKI

Contact

Feel free to contact Manisha Luthra or Boris Koldehofe for any questions.
